Basic Size: 35mm
Length (mm): 35mm-55mm
Rated Voltage (VDC): 24VDC 48VDC
Rated Torque (N.m): 0.12-0.24N.m
Rated Power (W): 37-74W
Rated Speed (Rpm): 3000Rpm
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) |
Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm2) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) | Encoder Resolution (P/R) |
| 14SYNE483730 | 3 | 8 | 48 | 3000 | 0.12 | 37 | 1.2 | 3.6 | 0.36 | 0.025 | 0.26 | 4.2 | 3.3 | 3.0 | 59 | 0.35 | 1000, 1024, 2500, 4096, 17bit |
| 14SYNE485630 | 3 | 8 | 48 | 3000 | 0.18 | 56 | 1.8 | 5.4 | 0.54 | 0.03 | 0.26 | 4.2 | 2.8 | 2.5 | 69 | 0.45 | |
| 14SYNE487430 | 3 | 8 | 48 | 3000 | 0.24 | 74 | 2.4 | 7.2 | 0.72 | 0.035 | 0.26 | 4.2 | 2.2 | 2.0 | 79 | 0.55 |
