Basic Size: 28mm
Length (mm): 46mm-66mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.03-0.06N.m
Rated Power (W): 12-24W
Rated Speed (Rpm): 4000Rpm
Electrical Specifications
| Motor Model | Rated Voltage(VDC) | Rated Speed(Rpm) | Rated Torque(N.m) | Rated Power(W) | Length(mm) |
| 11WLSE241240 | 24 | 4000 | 0.03 | 12.5 | 46 |
| 11WLSE241840 | 0.045 | 18.8 | 56 | ||
| 11WLSE242540 | 0.06 | 25 | 66 |
| Reducer Series | Transmission efficiency | Max radial load | Max axial load | Transmission torque | Reduction Ratio | Length(mm) |
| 1 | 90% | 35N | 20N | 0.3N.m | 3.7,5.2,6.75 | 25.6 |
| 2 | 81% | 35N | 20N | 1.2N.m | 14,19,25,27,35,45 | 34 |
| 3 | 73% | 35N | 20N | 2.5N.m | 51,71,100,139,181,236,307 | 42 |
