Motor Model	Number of Phase	Number of Poles	Rated Voltage (VDC)	Rated Speed (Rpm)	Rated Torque (N.m)	Rated Power (W)	Rated Current (A)	Peak Current (A)	Peak Torque (N.M)	Rotor Inertia (kg.cm²)	Torque Constant (N.m/A)	Torque Constant (V/krpm)	Line-Line Resistance (Ω)	Line-Line Inductance (mH)	Length (mm)	Weight (kg)
32BSTE481830	3	8	48	3000	0.6	188	5	15	1.8	0.6	0.11	10.5	0.9	0.7	99	1.5
32BSTE482530	3	8	48	3000	0.8	250	7	21	2.4	0.7	0.11	10.5	0.7	0.5	109	1.7

*Note: We can manufacture 24 volt DC servo motors according to customer's requirements.

Wiring Diagram

Dimensions(Unit: mm)

Functional Focus on Industrial Automation Applications
The 32BSTE Series DC Brushless Motor is engineered for industrial and automation users requiring consistent performance and long operational life. Targeted primarily at engineers and system integrators, this motor supports automation equipment demanding reliable torque output and precise speed control at rated 3000 RPM. Its compatibility with bdlc planetary gearmotor assemblies enhances mechanical power transmission in compact layouts. The option to customize voltage to 24 VDC further adapts this solution to diverse servo motor projects, meeting the niche demands of manufacturing and process control industries with strict operational standards.

Technical Specifications Supporting High Performance
Featuring rated voltages at 48 VDC with customization options, the 32BSTE Series delivers continuous power from 188W to 250W and torque between 0.6 N·m and 0.8 N·m. The motor’s 80mm frame size with lengths from 99mm to 109mm yields a lightweight form factor between 1.5 and 1.7 kg, ideal for tight-space installations. Key measurable attributes include a peak torque capability reaching up to 2.4 N·m and low rotor inertia values enhancing dynamic responsiveness. These technical parameters establish the motor’s suitability for integration with bdlc planetary gearmotor units, guaranteeing mechanical efficiency and precise control under high duty cycles.

Application Scope in Diverse Industry Settings
In application terms, the 32BSTE Series DC Brushless Motor supports high-precision automation workflows across sectors such as robotics, compact machinery, and industrial drives. Its brushless design reduces maintenance, optimizing total cost of ownership. The motor also complements systems that integrate bdlc planetary gearmotor technology to achieve enhanced torque multiplication and load distribution. This solution is especially valuable in environments requiring steady speed at 3000 RPM combined with robustness for mid-range power needs. Overall, it aligns well with industries focused on energy-efficient and reliable drive solutions for continuous operational performance.

Use Scenarios

Precision Automation in Robotics and Compact Machinery
In robotic and compact machinery manufacturing environments, precise, repeatable motion control is essential. The 32BSTE Series DC Brushless Motor serves as a core actuator driving high-performance tasks, leveraging its compatibility with bdlc planetary gearmotor assemblies to deliver controlled torque within limited spaces. The motor’s brushless design reduces thermal and mechanical stress, complying with stringent uptime requirements in automated production lines. Integration facilitates improved load distribution and speed regulation, enhancing robotic arm articulation and compact drive systems’ efficiency. This alignment with cutting-edge industrial automation workflows supports manufacturers in maintaining consistency and throughput.

Energy-Efficient Mid-Range Industrial Drive Solutions
Within mid-range industrial drive applications, including conveyor systems and assembly line equipment, the 32BSTE Series ensures dependable performance with minimal maintenance overhead. Its high torque output and rated speed of 3000 RPM, combined with low rotor inertia, contribute to energy-efficient operations. Coupling the motor with bdlc planetary gearmotor technology provides enhanced torque multiplication suitable for diverse load profiles, optimizing mechanical system performance. This setup complies with international safety and quality standards, facilitating seamless integration into existing industrial powertrain architectures while supporting sustainable manufacturing initiatives.

FAQ

What customization options are available for the 32BSTE Series DC Brushless Motor?
The 32BSTE Series offers customizable voltage options, including the standard 48 VDC and a 24 VDC servo motor variant. This flexibility supports diverse industrial applications, ensuring the bdlc planetary gearmotor solutions meet specific power and performance requirements.

What are the key maintenance requirements for this brushless motor series?
Thanks to its brushless design, the 32BSTE Series requires minimal maintenance, reducing downtime and operating costs. Regular checks of electrical connections and controlled operating environments can extend lifespan, making it a dependable choice for prolonged industrial use and integration with bdlc planetary gearmotor components.

How does Caida ensure quality and compliance for the 32BSTE Series?
Caida maintains ISO 9001:2015 certification and adheres to international standards such as CE, UL, and RoHS. All motors are produced through in-house processes with strict quality control, guaranteeing consistent performance and safety in environments demanding high reliability.

What delivery options does Caida offer for orders in Europe?
Caida provides local 72-hour delivery services across Europe via its overseas warehouses. Lead times depend on order specifics and customization needs. This efficient logistics network supports timely implementation of projects requiring the 32BSTE Series DC Brushless Motor and complementary bdlc planetary gearmotor systems.
