Basic Size: 32mm
Length (mm): 56mm-76mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.03-0.06N.m
Rated Power (W): 12-24W
Rated Speed (Rpm): 4000Rpm
Electrical Specifications
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) | Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm²) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) |
| 32RLSE241240 | 3 |
8 |
24 |
4000 |
0.03 | 12.5 | 0.7 | 2.1 | 0.09 | 0.01 | 0.04 | 4.48 | 1.9 | 0.9 | 56 | 0.22 |
| 32RLSE241840 | 0.045 | 18.8 | 0.9 | 2.7 | 0.13 | 0.02 | 0.04 | 5.23 | 2.5 | 1.1 | 66 | 0.38 | ||||
| 32RLSE242540 | 0.06 | 25 | 1.3 | 3.9 | 0.18 | 0.03 | 0.04 | 4.18 | 3.4 | 1.3 | 76 | 0.55 |
