Basic Size: 36mm
Length (mm): 54mm-74mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.04-0.08N.m
Rated Power (W): 16-32W
Rated Speed (Rpm): 4000Rpm
Electrical Specifications
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) | Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm²) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) |
| 36RLSE241640 | 3 |
8 |
24 |
4000 |
0.04 | 16.7 | 0.8 | 2.4 | 0.12 | 0.02 | 0.05 | 4.5 | 2.5 | 1.1 | 54 | 0.34 |
| 36RLSE242540 | 0.06 | 25 | 1.25 | 3.75 | 0.18 | 0.02 | 0.05 | 4.6 | 3.1 | 1.2 | 64 | 0.5 | ||||
| 36RLSE243340 | 0.08 | 33.5 | 1.7 | 5.2 | 0.24 | 0.03 | 0.05 | 4.5 | 3.4 | 1.3 | 74 | 0.66 |
