Basic Size: 42mm
Length (mm): 21.3mm-31.3mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.06-0.13N.m
Rated Speed (Rpm): 5000Rpm
Electrical Specifications
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) | Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm²) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) |
| 42ELTH243550 | 3 | 16 | 24 | 5000 | 0.06 | 35 | 2.2 | 6.6 | 0.18 | 0.13 | 0.03 | 2.8 | 2.0 | 1.5 | 21.3 | 0.12 |
| 42ELTH245050 | 0.1 | 50 | 3.2 | 9.6 | 0.3 | 0.23 | 0.03 | 2.8 | 1.5 | 1.0 | 26.3 | 0.18 | ||||
| 42ELTH247050 | 0.13 | 70 | 4.4 | 13.2 | 0.39 | 0.33 | 0.03 | 2.8 | 1.0 | 0.5 | 31.3 | 0.24 |
