Basic Size: 42mm
Length (mm): 21.3mm-31.3mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.06-0.13N.m
Rated Speed (Rpm): 5000Rpm
Electrical Specifications
| MotorModel | Rated Voltage (VDC) | Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Length (mm) |
| 42ELTH243550 | 24 | 5000 | 0.06 | 35 | 21.3 |
| 42ELTH245050 | 0.1 | 50 | 26.3 | ||
| 42ELTH247050 | 0.13 | 70 | 31.3 |
| Reducer Series | Transmission efficiency | Max radial load | Max axial load | Transmission torque | Reduction Ratio | Length(mm) |
| 1 | 96% | 150N | 80N | 6N.m | 5, 7, 10 | 39 |
| 2 | 94% | 150N | 80N | 10N.m | 16, 20, 25, 28, 35, 40, 50, 70 | 51.5 |
