Basic Size: 46mm
Length (mm): 25.3mm-35.3mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.08-0.16N.m
Rated Speed (Rpm): 5000Rpm
Electrical Specifications
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) | Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm²) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) |
| 46ELTH244050 | 3 | 16 | 24 | 5000 | 0.08 | 40 | 2.5 | 7.5 | 0.24 | 0.2 | 0.03 | 2.8 | 1.5 | 1.3 | 25.3 | 0.2 |
| 46ELTH246050 | 0.12 | 60 | 3.8 | 11.4 | 0.36 | 0.35 | 0.03 | 2.8 | 0.9 | 0.8 | 30.3 | 0.3 | ||||
| 46ELTH248050 | 0.16 | 80 | 5.1 | 15.2 | 0.48 | 0.5 | 0.03 | 2.8 | 0.4 | 0.3 | 35.3 | 0.4 |
