Basic Size: 75mm
Length (mm): 26.3mm-36.3mm
Rated Voltage (VDC): 24VDC
Rated Torque (N.m): 0.3-0.6N.m
Rated Speed (Rpm): 3000Rpm
Electrical Specifications
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) | Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm²) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) |
| 75ELTH249030 | 3 | 16 | 24 | 3000 | 0.3 | 90 | 5.8 | 17.4 | 0.9 | 1.5 | 0.05 | 4.5 | 0.5 | 0.2 | 26.3 | 0.5 |
| 75ELTH241430 | 0.45 | 140 | 8.9 | 26.7 | 1.35 | 1.9 | 0.05 | 4.5 | 0.4 | 0.1 | 31.3 | 0.7 | ||||
| 75ELTH241830 | 0.6 | 180 | 11.6 | 34.8 | 1.8 | 2.3 | 0.05 | 4.5 | 0.3 | 0.05 | 36.3 | 0.9 |
