Basic Size: 89mm
Length (mm): 20mm
Rated Voltage (VDC): 48VDC
Rated Torque (N.m): 1.5N.m
Rated Power (W): 470W
Rated Speed (Rpm): 3000Rpm
| Motor Model | Number of Phase | Number of Poles | Rated Voltage (VDC) |
Rated Speed (Rpm) | Rated Torque (N.m) | Rated Power (W) | Rated Current (A) | Peak Current (A) | Peak Torque (N.M) | Rotor Inertia (kg.cm2) | Torque Constant (N.m/A) | Torque Constant (V/krpm) | Line-Line Resistance (Ω) | Line-Line Inductance (mH) | Length (mm) | Weight (kg) |
| 89SSEH484730 | 3 | 16 | 48 | 3000 | 1.5 | 470 | 13.1 | 39.3 | 4.5 | 0.41 | 0.11 | 10.5 | 0.6 | 1.1 | 20 | 1.0 |
*Note：We can manufacture products according to customer's requirements.
