Model |
Voltage(V) |
Power (W)
|
No-load Parameters Speed(r/min) |
No-load Parameters Current (A) |
Load Parameters Rated Speed(r/min) |
Load Parameters
Starting Torque (mNm)
|
Load Parameters
Rated Torque Current(A)
|
Brush Life (H) |
Motor Weight (kg) |
|
Z2D06-12 |
12 |
6 | 3200 |
0.6Max. |
2950 |
19 |
0.8 | 2000 | 0.6 |
|
Z2DW06-12 |
12 |
6 | 3200 |
0.6Max. |
2950 |
19 |
0.8 | 2000 | 0.6 |
|
Z2D06-24 |
24 |
6 | 3200 |
0.3Max. |
2950 |
19 |
0.5 | 2000 | 0.6 |
|
Z2DW06-24 |
24 |
6 | 3200 |
0.3Max. |
2950 |
19 |
0.5 | 2000 | 0.6 |
|
Z2D06-90 |
90 |
6 | 3000 |
0.2Max. |
2800 |
20 |
0.3 | 2000 | 0.6 |
|
Z2DW06-90 |
90 |
6 | 3000 |
0.2Max. |
2800 |
20 |
0.3 | 2000 | 0.6 |
|
Gear Ratio
|
Speed (r/min)
|
Rated Torque (Nm)
|
|---|---|---|
| 3 | 983 | 0.05 |
| 3.6 | 819 | 0.06 |
| 5 | 590 | 0.08 |
| 6 | 492 | 0.09 |
| 7.5 | 393 | 0.12 |
| 9 | 328 | 0.14 |
| 10 | 295 | 0.16 |
| 12.5 | 236 | 0.20 |
| 15 | 197 | 0.24 |
| 18 | 164 | 0.28 |
| 20 | 148 | 0.28 |
| 25 | 118 | 0.35 |
| 30 | 98 | 0.42 |
| 36 | 82 | 0.51 |
| 40 | 74 | 0.57 |
| 50 | 59 | 0.71 |
| 60 | 49 | 0.76 |
| 75 | 39 | 0.96 |
| 90 | 33 | 1.15 |
| 100 | 30 | 1.27 |
| 120 | 25 | 1.53 |
| 150 | 20 | 1.91 |
| 180 | 16 | 2.29 |
| 200 | 15 | 2.55 |
