Model |
Voltage(V) |
Power (W)
|
No-load Parameters Speed(r/min) |
No-load Parameters Current (A) |
Load ParametersRated Speed(r/min) |
Load Parameters
Starting Torque (mNm)
|
Load Parameters
Rated Torque Current(A)
|
Brush Life (H) |
Motor Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
|
Z5D40-12 |
12 | 40 | 3100 |
2.0Max. |
2800 | 136 | 5.2 | 2000 |
1.9 |
|
Z5D40-24 |
24 | 40 |
3000 |
1.0Max. |
2800 |
136 |
2.6 |
2000 |
1.9 |
|
Z5D40-90 |
90 | 40 | 3200 |
0.3Max. |
3000 | 127 | 0.7 | 2000 |
1.9 |
|
Gear Ratio
|
Speed (r/min)
|
Rated Torque (Nm)
|
|---|---|---|
| 3 | 933 | 0.33 |
| 3.6 | 778 | 0.40 |
| 5 | 560 | 0.55 |
| 6 | 467 | 0.66 |
| 7.5 | 373 | 0.83 |
| 9 | 311 | 0.99 |
| 10 | 280 | 1.11 |
| 12.5 | 224 | 1.38 |
| 15 | 187 | 1.66 |
| 18 | 156 | 1.79 |
| 20 | 140 | 1.99 |
| 25 | 112 | 2.49 |
| 30 | 93 | 2.98 |
| 36 | 78 | 3.58 |
| 40 | 70 | 3.58 |
| 50 | 56 | 4.48 |
| 60 | 47 | 5.37 |
| 75 | 37 | 6.71 |
| 90 | 31 | 8.06 |
| 100 | 28 | 8.95 |
| 120 | 23 | 10.0 |
| 150 | 19 | 10.0 |
| 180 | 16 | 10.0 |
| 200 | 14 | 10.0 |
